price/Rs: 20,000
Cisco C3KX-NM-10G 10 Gigabit Ethernet Network Module for Catalyst 3560X/3750X Switches
The Cisco C3KX-NM-10G is a network module designed for use with Cisco Catalyst 3560X and 3750X series switches. It provides two 10 Gigabit SFP+ ports for high-speed uplink connections.
Here are the specifications and details of the C3KX-NM-10G:
- Compatibility: Cisco Catalyst 3560X and 3750X series switches
- Number of Ports: 4 (two SFP+ and two SFP)
- Port Type:
- Two SFP+ ports: Support 10 Gigabit Ethernet (10GbE) and 1 Gigabit Ethernet (GbE) SFP+ modules.
- Two SFP ports: Support 1 GbE SFP modules.
- Module Type: Hot-swappable
- Data Rate: 10Gbps (SFP+) and 1Gbps (SFP)
- Network Standards: 10GBASE-SR (850nm multimode fiber) and 10GBASE-CX4 (copper) for SFP+ ports. 1000BASE-SX, 1000BASE-LX, etc. for SFP ports (depending on the specific SFP module used).
- Distance: Up to 300 meters (multimode fiber) and up to 70 meters (copper) for SFP+ ports. Distance varies depending on the SFP module used for SFP ports.
Benefits:
- Increased Bandwidth: Provides high-speed 10 Gigabit Ethernet connections for demanding applications.
- Investment Protection: SFP+ ports can be used with both 10GbE and GbE SFP+ modules, allowing you to leverage existing investments and upgrade to 10GbE when needed.
- Flexibility: Supports a variety of SFP and SFP+ modules for different network types and distances.
- Scalability: Enables you to easily add 10 Gigabit Ethernet uplink capabilities to your Catalyst 3560X or 3750X switch.
Important Notes:
- The C3KX-NM-10G module itself does not come with SFP or SFP+ modules. These need to be purchased separately based on your specific network requirements.
- The supported distance and network standards will depend on the type of SFP or SFP+ module you use with this module.
- For detailed information on compatible SFP and SFP+ modules, refer to Cisco's compatibility matrix or consult your specific vendor.
Applications:
- Data center network uplinks
- High-performance computing environments
- Enterprise network core and distribution layers
- Service provider networks
By incorporating the C3KX-NM-10G module, you can significantly enhance the uplink bandwidth of your Cisco Catalyst 3560X or 3750X switch, enabling faster data transfer and supporting demanding network applications.
